High-Efficiency Ultrasonic Rubber Food Cutting Machine for Automotive

In today's fast-evolving automobile tire industry, precision and efficiency in manufacturing processes are not just desires; they are imperative demands. One innovative solution that stands at the forefront of meeting these demands is the ultrasonic rubber cutting technology, specifically designed for the nuanced needs of automotive tire production. Hanstyle’s latest offering, the High-Efficiency Ultrasonic Rubber Food Cutting Machine, is a game-changer in the field, promising unmatched precision and speed. The principle behind our cutting-edge technology is as sophisticated as it is effective. At its core, this cutting machine harnesses ultrasonic energy to achieve clean, precise cuts in rubber and similar materials, a task traditional cutting methods struggle with. The ultrasonic generator converts standard 50/60Hz current into an ultrasonic power of 20, 30, or 40kHz, creating vibrations in the cutting blade. These high-frequency vibrations allow the blade to slice through rubber smoothly and with minimal resistance, drastically reducing the energy expended in the cutting process. This method not only enhances the precision of cuts but also extends the blade's lifespan and maintains the integrity of the rubber, ensuring the final product meets the strict quality standards of the automotive industry.

Introduction:

---

Ultrasonic rubber cutting principle is through the ultrasonic generator 50 / 60Hz current into 20,30 or 40kHz power. The converted high frequency electrical energy is again converted into mechanical vibrations of the same frequency by means of transducers, which are then transmitted to the cutter through a set of amplitude modulator means which can vary the amplitude. The cutter transmits the received vibration energy to the cutting surface of the workpiece to be cut, in which the vibration energy is cut by activating the molecular energy of the rubber and opening the molecular chain. Particularly impressive are the variety of plastics that can be processed through Hanspire Automation ultrasonic rubber cutter. They range from delicate foils with minimal thickness to highly elastic materials that require a very sharp knife to hard and brittle materials.

Traditional cutting uses a knife with a sharp cutting edge, which concentrates very large pressure on the cutting edge and presses against the material being cut. When the pressure exceeds the shear strength of the material being cut, the molecular bond of the material is pulled apart, thereby achieving cutting. Therefore, the cutting effect of soft and elastic materials is not good, and it is more difficult for viscous materials. Comparing with traditional cutting, ultrasonic cutting is the use of ultrasonic energy to locally heat and melt the material being cut to achieve the purpose of cutting the material. It can easily cut resin, rubber, non-woven fabric, film, various overlapping composite materials and food. The principle of the ultrasonic cutting machine is completely different from the traditional pressure cutting.

Application:

---

It can easily cut resin, rubber, non-woven fabric, film, various overlapping composite materials. With our ultrasonic cutting solutions, wool materials used for covers or upholstery can be quickly and accurately cut and sealed.  It has been widely used for tire rubber parts, such as tread, nylon, sidewall, apex etc.

Demonstration Of The Working Performance:

---

Specifications:

---

Model No:	H-URC40	H-URC20
Frequency:	40Khz	20Khz
Blade Width(mm):	80	100	152	255	305	315	355
Power:	500W	800W	1000W	1200W	1500W	2000W	2000W
Blade material:	High Quality Steel
Generator Type:	Digital type
Power supply:	220V/50Hz

Advantage:

---

1. 1. High cutting precision, no deformation of rubber compound. 2. Good surface finish and good bonding performance. 3. Easy to apply to automated production. 4. Fast speed, high efficiency, no pollution. 5. Cross-cutting and slitting methods are available. 6. No deformation after cutting;cutting surface is very smooth. 7. Connect with PLC robotic arm to work.

2. Comments From Clients：

3. ---

Payment & Shipping:

---

Minimum Order Quantity	Price（USD）	Packaging Details	Supply Ability	Delivery Port
1 Unit	980~4990	normal export packaging	50000pcs	Shanghai



But what sets the High-Efficiency Ultrasonic Rubber Food Cutting Machine apart is its adaptability and versatility. Designed to meet the diverse needs of today's tire manufacturing processes, this machine seamlessly integrates into existing production lines, providing a boost in both speed and efficiency without significant downtime for implementation. Its state-of-the-art control system allows for easy adjustment of cutting parameters, ensuring optimal performance across a wide range of rubber types and thicknesses. Coupled with its robust construction and easy maintenance, the Hanstyle ultrasonic cutter represents a smart investment for any manufacturer looking to stay competitive in the fast-paced world of automobile production. As we look towards the future, it's clear that technologies like ultrasonic cutting will play a pivotal role in shaping the efficiency and sustainability of manufacturing processes across industries. Hanstyle is proud to be at the forefront of this revolution, offering solutions that not only meet the current needs of our customers but also anticipate the challenges of tomorrow. With our High-Efficiency Ultrasonic Rubber Food Cutting Machine, we are setting a new standard for precision, speed, and reliability in the automotive tire industry, ensuring our clients can continue to produce high-quality products in the most efficient way possible.
