Hanstyle Branson Transducer Replacement: Efficient 15KHz Ultrasonic Converter for Plastic Welding Machines

Immerse yourself in the world of advanced technology with Hanstyle's Branson Transducer Replacement - an intensity-driven 15KHz Ultrasonic Converter designed for plastic welding machines. This well-engineered product features resonating piezoelectric ceramics that operate at ultrasonic frequencies, ingeniously converting electrical signals into mechanical vibrations. This is made possible through the piezoelectric effect of its constituent material. Our Branson Transducer Replacement brings an unmatched intensity to the field of ultrasonic welding, leading to enhanced performance and precision in your operations. With its high-frequency ultrasonic waves, it ensures efficient welding of plastic components, offering a superior ultrasonic converter solution that is both reliable and economical. At Hanstyle, we understand the importance of quality and longevity. Therefore, we incorporate only the finest materials into our products, ensuring that our Branson Transducer Replacement adheres to the highest industry standards. Its robust and durable design ensures it can withstand intense usage, providing you with a long-lasting solution that delivers beyond your expectations.

Introduction:

---

Ultrasonic transducers are piezoelectric ceramics that resonate at ultrasonic frequencies and convert electrical signals into mechanical vibrations through the piezoelectric effect of the material.   When a transducer is used as a transmitter, the electrical oscillation signal sent from the excitation source will cause changes in the electric or magnetic field in the transducer's electrical energy storage element, thereby altering the mechanical vibration system of the transducer through some effect.   Generate driving force to vibrate, thereby driving the medium in contact with the mechanical vibration system of the transducer to vibrate and radiate sound waves into the medium.

Application:

---

The application of ultrasonic transducers is very extensive, which can be divided into industries such as industry, agriculture, transportation, daily life, medical treatment, and military. According to the implemented functions, it is divided into ultrasonic processing, ultrasonic cleaning, ultrasonic detection, detection, monitoring, telemetry, remote control, etc; Classified by working environment into liquids, gases, organisms, etc; Classified by nature into power ultrasound, detection ultrasound, ultrasound imaging, etc.

Demonstration Of The Working Performance:

---

Specifications:

---

Item NO.	Frequency(KHz)	Dimensions				Impedance	Capacitance（pF)			Input power (W)	Max Amplitude (um)
		Shape	Ceramic diameter （mm)	Qty of ceramic	Connect screw		Yellow	Grey	Black
H-7015-4Z	15	Cylindrical	70	4	M20×1.5	15	12000-14000	/	17000-19000	2600	10
H-6015-4Z	15		60	4	M16×1		8000-10000	10000-11000	12500-13500	2200	10
H-6015-6Z	15		60	6	M20×1.5		18500-20500	/	/	2600	10
H-5015-4Z	15		50	4	M18×1.5		12000-13000	13000-14500	/	1500	8
H-5015-4Z	15		40	4	M16×1		9000-10000	9500-11000	/	700	8
H-7015-4D	15	Inverted flared	70	4	M20×1.5		12500-14000	/	17000-19000	2600	11
H-6015-4D	15		60	4	M18×1.5		9500-11000	10000-11000	/	2200	11
H-6015-6D	15		60	6	1/2-20UNF		18500-20500	/	/	2600	11
H-5015-D6	15		50	6	1/2-20UNF		17000-19000	/	23500-25000	2000	11

Advantage:

---

1. 1. Energy saving and environmental protection 2. One by one testing to ensure that each transducer performance are excellent before shipping. 3. Low cost, high efficiency, high mechanical quality factor, obtaining high electric-acoustic conversion efficiency work at the resonance frequency points. 4. High welding strength and firm bonding. Easy to achieve automated production 5. Same quality, half the price, double the value. Each product reach to you have been test in our company three times, and with 72 hours continous working, to confirm it is well before you get it.

2. Comments From Clients：

3. ---

Payment & Shipping:

---

Minimum Order Quantity	Price（USD）	Packaging Details	Supply Ability	Delivery Port
1 Piece	280~420	normal export packaging	50000pcs	Shanghai



In addition, our Branson Transducer Replacement is incredibly user-friendly, with a simplistic design that is easy to install and use. This means that you can quickly integrate it into your operations, saving you valuable time and simplifying your processes. To enhance the proficiency of your plastic welding machines, consider Hanstyle's Branson Transducer Replacement. With its high power, efficient functionality, and top-quality design, it's the ultimate solution for your ultrasonic welding needs.
